Rugged RTK Base Station Receivers

  • Eview HB62 Rugged GNSS Base Station Receiver with Septentrio mosaic-X5

    HB62 Rugged GNSS Base Station Receiver — Septentrio mosaic-X5

    Rugged GNSS base station for RTK survey, drone bases and reference networks

    • Septentrio mosaic-X5, 448 channels, multi-constellation, multi-frequency
    • RTK base or rover: 0.6 cm + 0.5 ppm, 7 s initialization
    • Built-in web interface and NTRIP for correction streaming
    • RTCM v2.x/v3.x (MSM4–7), CMR, NMEA 0183 and SBF
    • Ethernet, 2 × RS232 and USB 2.0, 64 GB internal storage
    • IP67 housing, 9–36 V DC input, 1.5 W maximum
    • AIM+ anti-jamming, −40 °C to +85 °C operation

Eview rugged RTK base station receivers broadcast RTCM correction data to your rovers, so drones, robots, machines and survey equipment can work at centimetre accuracy anywhere, without depending on a network service.

  • HB62: rugged Septentrio mosaic-X5 base receiver with built-in web interface and NTRIP, for RTK survey, drone bases, construction and robot mowing sites.

Base stations: quick answers

Do I need my own RTK base station? Use one where NTRIP coverage is poor, where you need independence from a third-party service, or on long jobs at one site. See our NTRIP, RTCM and RINEX guide.

How do I get datasheets or a quote? Email sales@gnss-solutions.com with your application and quantity.
