ROSaic Deep Dive: Integrating Septentrio GNSS/INS Receivers with ROS 1 & ROS 2

Integrating a professional GNSS receiver into a ROS-based robot or autonomous system usually looks simple on paper and turns out to be messy in practice: binary protocols, axis-convention mismatches, differential correction plumbing, and receiver-state observability all surface as integration work. Septentrio’s official driver — ROSaic (septentrio_gnss_driver) — was built to remove exactly that friction. This guide walks through how the driver works under the hood, what it takes to configure GNSS/INS receivers for ROS 1 and ROS 2, and how the integration effort compares with rolling your own.

1. The Integration Gap ROSaic Closes

A flight controller (PX4, ArduPilot, Pixhawk) talks to GNSS receivers through basic NMEA/UBX sentences — enough to keep a vehicle flying, but not enough for serious autonomy. The SBF binary format, fine-grained RTK status, AIM+ interference-mitigation state, and multi-source differential inputs stay locked inside the receiver unless something on the onboard computer decodes them. ROS, running on a companion computer (Raspberry Pi, NVIDIA Jetson, NUC), is that something: it handles sensor processing, perception, planning, and fusion, while the flight controller handles real-time stabilization. ROSaic sits exactly in this gap — it converts receiver-native data into the standard ROS messages that fusion stacks like robot_localization consume directly.

2. Which Receivers Speak ROSaic

The driver targets Septentrio’s two main receiver families. The mosaic line — mosaic-X5 (multi-frequency, multi-constellation RTK), mosaic-G5 (cost-optimized), and mosaic-H (dual-antenna heading) — covers compact, low-power module integration. The AsteRx line — AsteRx-m3 Pro+, AsteRx-SB Pro+, AsteRx-SBi3 Pro, and related models — adds board and enclosed-receiver form factors, including GNSS/INS variants with dual-antenna heading. All of them bring the same underlying capabilities: centimeter-level RTK across GPS / Galileo / GLONASS / BeiDou / QZSS / NavIC, AIM+ interference mitigation with OSNMA signal authentication, and IMU-fused GNSS/INS output (position, velocity, attitude). The resilience claims are backed by the 2025 Jammertest, where receivers held centimeter accuracy through roughly 100 jamming scenarios and raised correct spoofing alarms.

3. Inside the Driver: Architecture in Brief

ROSaic is a single C++ repository maintained by Septentrio on GitHub that covers both ROS generations — ROS 1 (Melodic, Noetic) and ROS 2 (Foxy through Galactic, Humble, Iron, Jazzy, Kilted, Lyrical, Rolling, and later). Data arrives in SBF binary plus selected ASCII/NMEA messages and is exposed as sensor_msgs/NavSatFix, gps_common/GPSFix, and — for INS models — nav_msgs/Odometry.

Three implementation details matter most in practice:

• Native SBF decoding. The driver parses PVTGeodetic, PosCovGeodetic, ChannelStatus, MeasEpoch, AttEuler, AttCovEuler, VelCovGeodetic, DOP, and related blocks, so RTK status, signal health, and attitude data never have to pass through a lossy NMEA translation.
• Built-in NED→ENU conversion. Septentrio outputs in the NED convention; ROS expects ENU. The driver resolves the axis mismatch internally, with an explicit convention selector for INS models (use_ros_axis_orientation), and follows the REP 103 / REP 105 frame conventions including an optional insert_local_frame odom frame.
• Observability. AIM+ and OSNMA anti-jamming / anti-spoofing status is published to ROS topics, turning receiver state into something you can monitor, log, and alert on.

Install & Launch in One Command

Binary packages are released through ROS’s official bloom pipeline, so installation is a single apt command on any supported distro (Noetic, Humble, Iron, Jazzy, Rolling):

• sudo apt-get install ros-$ROS_DISTRO-septentrio-gnss-driver
• ROS 1: roslaunch septentrio_gnss_driver rover.launch param_file_name:=rover
• ROS 2 (composed node): ros2 launch septentrio_gnss_driver rover.launch.py file_name:=rover.yaml
• ROS 2 (standalone node): ros2 launch septentrio_gnss_driver rover_node.launch.py file_name:=rover.yaml

Configuration lives in YAML: rover.yaml carries the full parameter set, while gnss.yaml / ins.yaml are slim GNSS- or INS-only profiles. Building from source uses the standard colcon workflow (colcon build --packages-up-to septentrio_gnss_driver) with dependencies on gps-msgs, Boost, GeographicLib (LLA↔UTM) and libpcap for PCAP replay.

Connection Modes

4. ROS Topics & Messages: What You Get Out of the Box

The driver translates SBF blocks into 30+ optional ROS topics, all carrying standard message headers (receiver timestamp + frame_id). The navigation-stack-ready topics are the ones that matter for robot_localization integration:

Status and diagnostics topics turn receiver state into something you can monitor and alert on:

Every SBF block also has a same-named custom message (PVTGeodetic, AttEuler, BaseVectorGeod/Cart, MeasEpoch, INSNavGeod/Cart, ExtSensorMeas, IMUSetup…) plus standard NMEA topics (/gpgga, /gprmc, /gpgsa, /gpgsv), each gated by its publish.* switch. publish_only_valid limits output to timestamp-valid blocks.

5. Compatibility & Firmware Requirements

Firmware matters more than most people expect — several driver features only exist on recent releases. The official README documents these minimums and functional limits:

6. GNSS/INS Setup: The YAML Walkthrough

INS models (AsteRx-i3 D Pro(+), AsteRx SBi3 Pro(+), AsteRx RBi3 Pro(+)) fuse IMU rotation/acceleration with GNSS position/velocity through a Kalman filter, producing a 9D state (3 position + 3 velocity + 3 attitude) that is more accurate and more robust to GNSS outages than 7D/8D dual-antenna solutions. A few configuration decisions beyond a standard GNSS-only setup make this work — they live in the driver’s YAML file:

• receiver_type: ins — switches the driver into INS receiver mode (GNSS-only models use gnss).
• use_ros_axis_orientation — pick NED or ENU to match your robot’s frame convention.
• ins_spatial_config — the geometry block: IMU orientation angles (imu_orientation theta X/Y/Z — the receiver’s IMU reference direction is printed on top of the unit), plus the three lever-arm offsets: poi_lever_arm (point of interest), ant_lever_arm (GNSS antenna reference point to IMU — skip this and INS position will be wrong), and vsm_lever_arm (velocity sensor to IMU). Alternatively set get_spatial_config_from_tf: true to read them from the tf tree.
• ins_initial_heading — auto (derived from GNSS motion, default) or stored (reuse the last heading before power-off — useful for parking/restart scenarios).
• ins_std_dev_mask — the acceptance threshold for attitude (≤5°) and position (≤10 m) standard deviation; effectively the quality gate of the INS solution.
• ins_use_poi — which point the navigation solution reports (configured POI or primary antenna); must be on when TF publishing is enabled (default true).
• ins_vsm — velocity sensor measurement input for tighter INS accuracy; velocity can come from ROS (/odometry_vsm or /twist_vsm), a TCP/IP device, or serial, and non-holonomic constraints (zero lateral/vertical speed for Ackermann vehicles) can be applied even with x-only speed sensing.

These parameters are not cosmetic: they define the spatial relationship between the IMU, antennas, and vehicle origin, and errors here propagate directly into fused position and attitude output. Output rates are also worth knowing — raw IMU can reach 200 Hz, while the fused INS solution publishes at 100 Hz.

Once running, INS receivers publish topics backed by the INSNavGeod, INSNavCart, ExtSensorMeas, IMUSetup, and VelSensorSetup SBF blocks. Verification is standard ROS workflow — ros2 topic list to enumerate, ros2 topic echo <topic> to inspect — and the bundled PlotJuggler integration renders acceleration, trajectory, and attitude streams in real time.

7. RTK Corrections, OSNMA & Time Sync

Multi-source differential, in parallel. The receiver can hold several correction links open at once and automatically uses the closest source: up to 3 NTRIP mounts (ntrip_1~3, RTCMv2/v3 and CMRv2, TLS, GGA reporting policies), up to 5 TCP/IP streams (ip_server_1~5), and up to 5 serial inputs (serial_1~5) for local base-station radios. keep_open: true keeps links alive after the driver exits.

OSNMA anti-spoofing. Galileo OSNMA authentication is controlled per receiver via osnma.mode: off, loose (authenticated or unknown-status satellites participate), or strict (only authenticated satellites — requires NTP sync). Authentication state is then observable on the /galauthstatus topic.

Time. use_gnss_time: true builds message timestamps from GNSS time (TOW/WNC) — the host must be NTP/PTP-synchronized, and a Septentrio receiver can itself act as a Stratum-1 NTP server without internet. latency_compensation removes receiver processing delay, and polling_period (default 500 ms) controls the PVT/rest refresh rate — set it to 0 for block-driven (OnChange) updates.

8. Debugging, Testing & Extending the Driver

ROSaic is unusually testable for a hardware driver. SBF logs and PCAP captures can be fed straight back in as device input for offline replay, so field issues reproduce without the receiver on the bench (set leap_seconds correctly for replay with GNSS time). /diagnostics emits standard ROS diagnostics, activate_debug_log turns on driver-level logging, and publish_only_valid filters to timestamp-valid blocks. Adding a new message type is a documented 7-step flow (new .msg → typedefs.hpp → SBF parser → handler registration → publish.* parameter → data-stream config), so the driver is genuinely extensible in-house. Known gotchas: configure_rx: true overwrites receiver parameters, string parameters like hw_flow_control need quotes, and serial access requires the dialout group.

9. Integration Cost: Official Driver vs. Building Your Own

The honest way to evaluate a driver is against the alternative. For a typical outdoor inspection robot running ROS 2 Humble with robot_localization doing GNSS/IMU fusion, the comparison looks like this:

Timelines are engineering estimates — actual results depend on team experience and project complexity.

The value story reduces to four levers: time (configuration replaces driver development), risk (an upstream maintainer owns compatibility), capability (multi-source RTK, AIM+ reporting, and frame conversion all ship in the box), and ecosystem fit (standard messages drop straight into robot_localization and other fusion frameworks).

10. Beyond ROS: the Flight Controller Route

ROSaic is not the only integration path. mosaic-series receivers also work directly with Pixhawk, ArduPilot, and PX4 Autopilot, and Septentrio’s mosaicHAT reference design (mosaic-X5 + Raspberry Pi) plus the Robotics Interface Board (RIB) simplify hardware bring-up. Teams can therefore start on the flight-controller route and move to a full ROS stack later — or run both, with the receiver serving either side without changes. Eview’s mosaic-X5 based receivers and OEM GNSS boards inherit this whole ecosystem, as do our anti-jamming GNSS solutions for autonomy applications. For a hands-on first step with the driver itself, see our step-by-step mosaic-X5 ↔ ROS setup guide.

11. FAQ

Is the Septentrio ROS driver open source?

Yes — septentrio_gnss_driver is maintained in the open on Septentrio’s GitHub under the ROSaic brand (BSD-3-Clause), free to use, and actively updated across ROS 1 and ROS 2 releases.

Do I need a GNSS/INS receiver to benefit from ROSaic?

No. GNSS-only models (mosaic-X5, mosaic-G5, AsteRx m3 Pro+) publish NavSatFix and GPSFix. INS models additionally publish Odometry with full attitude, but everything else — SBF parsing, NED→ENU, multi-source RTK, AIM+ status — works identically either way.

Which firmware version do I need for OSNMA and the latest INS features?

GNSS receivers need at least 4.12.1 for OSNMA and 4.14 for PTP server clock. INS receivers need 1.3.2 for NTP, 1.4 for OSNMA, and 1.4.1 for the improved velocity-sensor handling. Check the firmware matrix in Section 5 for the full breakdown.

Why does the driver need to convert NED to ENU?

Septentrio receivers follow the NED (North-East-Down) convention, while ROS frames use ENU (East-North-Up). Without conversion, fused position and orientation would be subtly wrong. ROSaic handles this internally, and INS models expose an explicit convention selector.

How do I configure lever arms for an INS receiver?

In the driver YAML, under ins_spatial_config: set imu_orientation for mounting angles and the three lever-arm offsets — poi_lever_arm, ant_lever_arm (antenna to IMU), and vsm_lever_arm (velocity sensor to IMU). These physical offsets directly affect fusion accuracy.

Can I develop against ROSaic without hardware?

Yes — the driver supports PCAP and SBF replay, so you can capture receiver data once and exercise the full pipeline offline, which is a practical way to validate message output and fusion behavior before hardware is on the bench.

12. Sources & References

Author: Jack Wang · Updated: 2026-09-01· External references as listed above.
