Evaluation board for prototyping and integrating mosaic-G5 RTK
- Eview evaluation board built around the Septentrio mosaic-G5 P3 or P3H
- Centimetre-level RTK: 0.6 cm + 0.5 ppm horizontal
- P3H version: dual-antenna heading 0.15° (1 m baseline)
- USB Type-C with two virtual serial ports for direct PC setup
- 2 × TTL UART, Ethernet, PPS output and event input
- Kit with RJ45 adapter, 2 × TTL-to-RS232 and 2 × MCX-to-TNC cables
- Compact 80 × 41 mm board, 5 V supply
-
OEM GNSS receiver board with Ethernet for system integration
- Septentrio AsteRx-m3 Pro+, 544 hardware channels
- Centimetre-level RTK: 0.6 cm + 0.5 ppm, 7 s initialization
- Dual-antenna heading 0.15° and pitch/roll 0.25° (1 m baseline)
- Up to 100 Hz position and measurements, <10 ms latency
- AIM+ anti-jamming and Galileo OSNMA anti-spoofing
- Ethernet, 3 × UART, USB Type-C and microSD up to 32 GB
- Board size 71.8 × 50.2 × 12.5 mm, 4.5–12 V input
Eview OEM GNSS boards are board-level, high-precision receivers for engineers who build GNSS into their own robots, drones, vehicles and embedded systems. Each board carries a Septentrio module with AIM+ anti-jamming, and Eview adds integration-ready interfaces, documentation and engineering support.
- HB59 OEM GNSS receiver board: Septentrio AsteRx-m3 Pro+, centimetre RTK, dual-antenna heading and up to 100 Hz output with under 10 ms latency, for fast robots and autonomous vehicles.
- G5P3H EVK evaluation board: for testing the compact, low-power Septentrio mosaic-G5 P3 / P3H before designing it into your own hardware.
OEM GNSS boards: quick answers
What is the best GNSS board for robotics? For robots that need heading at standstill and fast control loops, a dual-antenna RTK board such as the HB59. For small, battery-powered robots, a mosaic-G5 design for its small size and low power.
Which interfaces and outputs are supported? UART with NMEA and Septentrio SBF, RTCM 3 corrections input, and support for ROS 2, ArduPilot and PX4 through the Septentrio drivers. See the NTRIP, RTCM and RINEX integration guide.
How do I get a datasheet or integration help? Email sales@gnss-solutions.com with your platform, interfaces and volumes.
