EV210 is a compact multi-frequency GNSS antenna for lightweight UAVs. Supporting GPS L1/L2, BDS B1/B2/B3, GLONASS G1/G2, and Galileo E1 in a Φ27.5×57.6 mm housing, it delivers 33±2 dB LNA gain and IP67 sealing — for precision agriculture, aerial photography, telemetry, and surveillance drones.
Compact multi-frequency GNSS antenna for UAV and drone integration. Supports GPS L1/L2, BDS B1/B2/B3, GLONASS G1/G2/G3 and Galileo E1/E5b/E6. 33 dB LNA · IP65 · 49.8×38 mm · -40°C to +70°C. Suited for surveying, agriculture, aerial photography and patrol.
Full-frequency multi-band GNSS vehicle antenna supporting GPS L1/L2/L5, BDS B1/B2/B3, GLONASS L1/L2/L3, Galileo E1/E5a/E5b/E6 and L-Band. 3.5 dBi gain · 33 dB LNA · IP67 · 107×43 mm · -40°C to +85°C. Designed for agricultural equipment, UAVs and vehicle-mounted applications.
Professional full-frequency choke ring GNSS reference antenna. BDS B1/B2/B3, GPS L1/L2/L5, GLONASS L1/L2/L3, Galileo E1/E5a/E5b/E6, L-Band. Phase centre accuracy plus or minus 1mm, 6 dBi gain, IP67. For CORS networks & geodetic survey.
The HB10 is a compact dual-antenna GNSS positioning and orientation RTK receiver powered by the Septentrio AsteRx-m3 Pro+. Designed for industry drones, autonomous vehicles, precision control and hazard monitoring, it delivers 0.6 cm + 0.5 ppm RTK accuracy with 0.15° heading precision at a 100 Hz update rate and ultra-low <10 ms latency. Septentrio’s AIM+ anti-interference, APME+ multipath suppression, OSNMA anti-spoofing and LOCK+ robust tracking ensure reliable positioning in demanding RF environments.
Multi-frequency GNSS receiver powered by Septentrio Mosaic X5 — 100 Hz RTK, AIM+ anti-jamming, 0.6 cm accuracy, compact 60 g design for UAVs, AGVs and robotics.
Multi-frequency GNSS receiver with dual-antenna heading — powered by Septentrio Mosaic H-series. 0.15° heading, 20 Hz RTK, AIM+ Advanced, only 50 g.
Compact dual-antenna RTK GNSS heading board powered by Septentrio Mosaic-G5 P3H. 0.6 cm RTK accuracy, 0.15 degree heading, AIM+ anti-jamming, IONO suppression, RM3100 magnetic sensor — under 7 s RTK init with over 99.9% reliability.
The HB52H / HB52 is an ultralight compact all-constellation, all-frequency RTK GNSS receiver powered by the Septentrio mosaic-G5. With 789 hardware channels, 0.6 cm + 0.5 ppm RTK accuracy and ultra-precise 1.4 ns timing, it supports dual-antenna heading output (HB52H) and single-antenna positioning (HB52). Designed for UAVs, autonomous robots and precision control systems, Septentrio’s AIM+ anti-interference, APME+, IONO+, LOCK+ and RAIM+ technologies ensure reliable performance in complex environments.
The HB59 is a high-performance multi-function OEM GNSS receiver powered by the Septentrio AsteRx-m3 Pro+. Configurable as a base station or rover, it delivers centimetre-level RTK positioning across multi-frequency, multi-satellite constellations. In dual-antenna mode it provides heading with pitch and roll information for reliable static and dynamic navigation — designed for drones, autonomous robots, precision control and unmanned driving, with Septentrio’s AIM+ anti-interference and inertial-navigation support for demanding environments.
The HB6 is a compact multi-band, multi-constellation P-Box terminal GNSS receiver supporting both single-antenna positioning via the Septentrio mosaic-X5 and dual-antenna heading via the Septentrio mosaic-H. With 448 hardware channels, 100 Hz update rate, <10 ms latency and 0.6 cm + 0.5 ppm RTK accuracy, it is designed for UAVs, drones, autonomous vehicles and unmanned systems. AIM+ anti-interference, APME+, IONO+, LOCK+ and RAIM+ protection ensure reliable high-precision positioning in demanding environments.
The HB6 Pro is a compact multi-band, multi-constellation GNSS box receiver supporting both single-antenna positioning via the Septentrio mosaic-X5 and dual-antenna heading via the Septentrio mosaic-H. With 448 hardware channels, 100 Hz update rate, <10 ms latency and 0.6 cm + 0.5 ppm RTK accuracy, it is designed for UAVs, drones, autonomous vehicles and unmanned systems. AIM+ anti-interference, APME+, IONO+, LOCK+ and RAIM+ protection ensure reliable performance in demanding RF environments.
Full-frequency RTK GNSS receiver integrated into a compact antenna-style housing. Powered by Septentrio mosaic-G5 P3 — 789 channels, 0.6 cm RTK, 0.03° heading, AIM+ anti-jamming. M12-4P connector with 10 m cable. For UAVs, robots and automation systems.
HBEV322 / HBEV322H is a compact, lightweight all-constellation RTK GNSS receiver with integrated QMC5883L compass, powered by the Septentrio mosaic-G5 P3H module. At just 14 g and φ44 × 40.6 mm, it delivers centimetre-level RTK positioning and 0.15° dual-antenna heading for UAV, AGV, ADAS, and robotic platforms.
