Lightweight multi-band GNSS antenna for civil drones and UAV aviation
- GPS, GLONASS, Galileo and BeiDou, multi-frequency, plus L-band
- Includes BeiDou B3, GLONASS G3 and Galileo E6
- Active antenna: 36 ± 2 dB LNA, noise figure ≤2 dB
- Phase-centre error ±3 mm, axial ratio ≤3 dB
- Weight ≤60 g, Φ90 × 24.6 mm
- IP67 when installed, −40 °C to +85 °C
- TNC connector, four 4.3 mm mounting holes
-
Small, light multi-frequency GNSS antenna for UAVs and compact rovers
- GPS L1/L2, GLONASS G1/G2, Galileo E1, BeiDou B1/B2/B3
- Active antenna: 33 ± 2 dB LNA gain, noise figure ≤1.3 dB
- Phase-centre error ±3 mm, axial ratio ≤3 dB
- High out-of-band rejection against cellular and radio-link interference
- Supply DC 3.3–12 V from the receiver’s antenna port
- Compact cylinder Φ27.5 × 57.6 mm with direct SMA (male) mount
- IP67 when mounted, −40 °C to +70 °C operation
-
Flange-mount multi-band GNSS antenna for drones and light vehicles
- GPS L1/L2, GLONASS G1/G2/G3, Galileo E1/E5b/E6, BeiDou B1/B2/B3
- Active antenna: 33 ± 2 dB LNA gain, noise figure ≤1.3 dB
- RHCP with axial ratio ≤3 dB
- High out-of-band rejection against base-station interference
- Supply DC 3.3–12 V, current ≤50 mA
- Four-hole flange (40 mm hole spacing), 600 mm cable to SMA (male)
- IP65, −40 °C to +70 °C operation
-
Magnetic-mount multi-band GNSS antenna for vehicles and autonomous machines
- GPS, GLONASS, Galileo and BeiDou, multi-frequency, plus L-band
- Includes GPS L5, Galileo E6 and BeiDou B2a
- Active antenna: 33 ± 2 dB LNA, noise figure ≤2 dB
- Phase-centre error ±3 mm, 4 dBi maximum gain
- Magnetic mount, 75 × 75 × 30 mm, ≤70 g
- IP67, −40 °C to +85 °C
- 3 m RG174 cable with SMA male connector
-
Rugged full-band GNSS antenna for agricultural machines, vehicles and UAVs
- GPS L1/L2/L5, GLONASS L1/L2/L3, Galileo E1/E5a/E5b/E6, BeiDou B1/B2/B3, L-band
- Active antenna: 33 ± 2 dB LNA gain, noise figure ≤1.3 dB
- Phase-centre error ±3 mm, axial ratio ≤3 dB
- High out-of-band suppression for stable tracking near radios
- Supply DC 3.3–12 V, current ≤50 mA
- 5/8″-11 thread mount, 650 mm cable to SMA (female)
- IP67, −40 °C to +85 °C, vibration, impact and salt-spray tested
Eview multi-frequency GNSS antennas are designed for RTK drones, rovers, vehicles and base stations. Every model tracks all major constellations on multiple bands, so your receiver can resolve RTK quickly and keep a fix near interference and obstructions.
- EV108: multi-band aviation GNSS antenna, 60 g, for civil drones.
- EV210: compact cylinder UAV GNSS antenna, IP67.
- EV220: flange-mount multi-band drone antenna with Galileo E6.
- EV288: full-band RTK antenna with L5, E6 and L-band, IP67, for rovers and base stations.
- EV226: magnetic-mount multi-band vehicle antenna, IP67.
How to choose a GNSS antenna
Match the bands to your receiver. A multi-frequency receiver needs a multi-frequency antenna (L1/L2/L5, plus E6 or L-band if you use them), or you lose accuracy and fix speed.
Choose size and mounting for the platform. Light, compact antennas for UAVs; magnetic or pole mounts for vehicles and rovers; full-band antennas for base stations.
Check environment and installation. IP67 for outdoor use, a clear sky view, distance from radios and motors, and a good cable. All Eview antennas are active antennas, powered by the receiver through the coax.
Need help choosing? Email sales@gnss-solutions.com with your receiver and platform.
